Handlebar installation

Do not attempt to straighten a bent handlebar as this may dangerously weaken the handlebar.

HANDLEBAR INSPECTION

HANDLEBAR REMOVAL

HANDLEBAR CHAS

K-2

HANDLEBAR CHAS

1. Remove:

• Grip (Left)

************************************************************ Removal Steps

Remove the left grip end

Blow with compressed air between the handlebar and adhesive side of the grip to remove.

************************************************************

1. Inspect:

• Handlebar Bends/Cracks/Damage, Replace

s WARNING

1. Install:

• Handlebar Ø

NOTE:

Apply a light coat of lithium soap base grease onto the handlebar right end.

Align the match marks §a on the handlebar with the

lower handlebar holder upper surface.

2. Install:

• Grip Ø

Order	Job name/Part name	Quantity	Remarks
	Grip (left)		section.
	Handlebars
	Screw/hut	1/1
Reverse the removal procedure for
installation.

HANDLEBAR CHAS
