Primary sheave eng. Cylinder and piston eng

F-15

PRIMARY SHEAVE ENG

CYLINDER AND PISTON ENG

F-14

Use only new piston pin clips

3. Install:

• Gasket (cylinder) New

• Dowel pins

4. Position:

• Piston rings

NOTE:

Offset the piston ring end gaps as shown

§a Top ring end

§b Oil ring end (lower)

§c Oil ring (upper)

§d 2nd ring end

5. Lubricate

• Piston outer surface

• Piston ring

• Cylinder inner surface

Engine Oil

6. Install:

• Cylinder

NOTE:

Install the cylinder with one hand while compressing the piston rings with the other hand

Pass the timing chain and timing chain guide (exhaust side) through the timing chain cavity.

V-BELT, CLUTCH AND SECONDARY/

V-BELT, CLUTCH AND SECONDARY/

V-BELT, CLUTCH AND SECONDARY/ PRIMARY SHEAVE

AIR FILTER COVER AND CRACK CASE COVER

V- BELT, CLUTCH AND SECONDARY/ PRIMARY SHEAVE

* Grease (90890-69927)

Order	Job name/part name	Quantity	Remarks
	Removal of V-belt, clutch and			Remove the parts in order
secondary/primary sheaves
Nut/´plain washer	1/1/1 1/1	See section on PRIMARY SHEAVE
	Primary fixed sheave/washer	REMOVAL
	Nut			See section on SECONDARY SHEAVE
	Clutch housing		AND V-BELT REMOVAL
	Clutch assembly		See section on SECONDARY SHEAVE
	V-belt		INSTALLATION
	Primary sliding sheave
	Collar		See section on PRIMARY SHEAVE
	Counterweight track/Counter weights	1/6	ASSEMBLY

Order	Job name/part name	Quantity	Remarks
	Removal of crankcase filter		Remove the parts in order
cover and crankcase (left)
Crankcase filter cover seal
	Crankcase filter element
	Crankcase cover protector
	Crankcase cover (left)
	Crankcase cofer gasket
Reverse the removal procedure for
installation

V-BELT, CLUTCH AND SECONDARY/
