Inspection

1. Inspect:

• Radiator Ø

Obstruction —(Blow out with compressed air through the rear of the radiator.

Flattened fins —(Repair or replace.

If flattened over 20% of radiator fin, repair or replace the radiator.

CAUTION

Use only specified adhesive to repair the radiator.

2. Inspect

• Radiator hoses

• Radiator pipes Cracks/damages —(Replace

3. Measure

• Radiator cap opening pressure

• Radiator cap opens at a pressure below the spe- cified pressure —(Replace

	Radiator cap opening pressure: 110 kPa
(1.1 kg/cm2, 1.1bar)

*********************************************************** Measurement steps

Attach the radiator cap tester Ø and adapter Ø to the

Order	Job name/Part name	Quantity	Remarks
	Radiator removal		Remove the parts in order
Drain the coolant	Refer to COOLANT REPLACEMENT”
	section in Chapter 3.
Footrest board, under cover, leg shield	Refer to the “COVER AND PANEL”
	section in Chapter 3.
Ventilador cables
	Filler hose (radiator)
	Outlet hose (radiator)
	Inlet hose (radiator)
	Radiator
Reverse the removal procedure for
installation.

radiator cap Ø.

Radiator cap tester: 90890-01325

Adapter:

Apply the specified pressure for 10 seconds, and make sure there is no pressure drop.

4. Inspect:

• Fan motor assembly Damage —(Replace

Malfunction —(Check and repair

Refer to “COOLING SYSTEM” in “CHAPTER 8”

5. Inspect:

• Pipes

Cracks/damage —(replace.
