Algorithm

The steps of the Newton-Raphson method to find the root of an equation f(x) = 0 are

1. Evaluate f¢(x) symbolically

2. Use an initial guess of the root, x_i, to estimate the new value of the root x_{i +1} as

3. Find the absolute relative approximate error, as

4. Compare the absolute relative approximate error, with the pre-specified relative error tolerance, . If > , then go to step 2, else stop the algorithm. Also, check if the number of iterations has exceeded the maximum number of iterations.

Figure 1. Geometrical illustration of the Newton-Raphson method

Example 1:

You are working for ‘DOWN THE TOILET COMPANY’ that makes floats for ABC commodes. The ball has a specific gravity of 0.6 and has a radius of 5.5 cm. You are asked to find the distance to which the ball will get submerged when floating in water.
