Steering chas

INSPECTION

Securely support the steering shaft so that there is no danger of it falling down.

Stand the scooter on a level surface.

STEERING CHAS

K-4

STEERING CHAS

STEERING REMOVAL

s WARNING

Securely support the scooter so that there is no danger of falling over.

1. Remove:

• Ring nut (upper)

• Lock washer Ø

• Ring nut centre Ø

• Rubber washer

2. Remove:

• Ring nut (lower) Ø

• Steering bracket

Exhaust and steering nut wrench: 90890 - 01268

s WARNING:

Order	Job name/Part name	Quantity	Remarks
	Ball bearing Ball bearing Ball race 2 Ball race 3 Ball race 4
		Refer to the “STEERING INSTALLATION” section
	Reverse the removal procedure for installation.

1. Wash the bearing and bearing races with a solvent.

2. Inspect:

• Bearings

• Bearing races Pitting/Damage —(Replace

************************************************************ Bearing race replacement steps

• Remove the bearing races on the head pipe using long rod Ø and the hammer as shown

• Remove the bearing race on the under bracket using the floor chisel Ø and the hammer as shown

• Install the new dust seal and races

************************************************************

NOTE:

• Always replace bearings and races as a set

• Replace the dust seal whenever the steering head is disassembled.

CAUTION:

If the bearing race is not fitted properly, the head pipe could be damaged.
