Electrical starting system elec

L-11

ELECTRICAL STARTING SYSTEM ELEC

+

+

3. Starter motor

• Connect the battery positive terminal and starter motor cable using a jumper lead.

• Check the starter motor operation.

DOES NOT MOVE

Repair or replace the starter motor

6. Main switch

Refer to “CHECKING SWITCHES” section in CHAPTER 8

CONTINUITY

NO CONTINUITY

Replace the main switch

MOVES

s WARNING:

A wire used as a jumper lead must have the equivalent capacity as that of the battery lead or more, otherwise it may burn.

7. Alarm connection

• Check the L/W bridge terminal (If it does not have an alarm)

CONTINUITY

8. Sidestand switch

Refer to “CHECKING SWITCHES”

section.

NO CONTINUITY

Replace the bridge terminal

NO CONTINUITY

Replace the sidestand switch

4. Starter relay

• Disconnect the relay unit coupler from the wireharness • Connect the pocket tester (Ω x 1) and battery (12v) to the relay unit coupler terminals

Battery (+) lead—( Red/ White terminalØ Battery (-) lead—( Blue/ White terminalØ

• Check the starter relay for continuity

Tester (+) lead—(TerminalØ Tester (-) lead—(Terminal

CORRECT

CONTINUITY

NO CONTINUITY

Replace the starter relay

9. Front/rear brake switch

Refer to “CHECKING SWITCHES”

section.

NO CONTINUITY

Replace the brake switch

CORRECT

10.

5. Starting circuit cut-off relay

• Disconnect the starting circuit cut-off relay coupler from the wireharness. • Connect the pocket tester (Ω x 1) and battery (12 v) to the starting circuit cut -off relay coupler terminals.

Battery (+) lead—(Ø terminal Battery (-) lead—(terminal

Battery (+) lead—(Ø terminal Battery (-) lead—(Ø terminal

Starter switch

Refer to “CHECKING SWITCHES”

section.

NO CONTINUITY

Replace the right handlebar switch

CORRECT

CONTINUITY

+

NO CONTINUITY

Replace the starting circuit cur-off-relay

11. Wiring connection

• Check the connections of the entire starting system

Refer to “CIRCUIT DIAGRAM”.

POOR CONNECTION

Correct
