Front brake chas

J-9

FRONT BRAKE CHAS

Align the plain washer notch and master cylinder edge for assembly.

3. Air bleed:

• Brake system

Refer to ‘AIR BLEEDING’ section in CHAPTER 3.

s WARNING

Use only designated quality brake fluid; otherwi- se, the rubber seals may deteriorate, causing lea- kage and poor brake performance.

Refill with the same type of brake fluid; mixing fluids may result in a harmful chemical reaction and lead to poor performance.

Be careful that water does not enter; the signifi- cantly lower boiling point of the fluid may result in vapour lock.

4. Inspect:

• Brake operation.

CALIPER CALIPER DISASSEMBLY

23 Nm (2,3 m•kg)

Order	Job name/Part name	Quantity	Remarks
	Caliper disassembly Clip Pad support Spring Brake pad Bleed screw/Cap	1/1		Remove the parts in order   Refer to “BRAKE CALIPER DISASSEMBLY/ASSEMBLY” section.   Reverse the disassembly procedure for assembly.

23 Nm (2,3 m•kg)

Order	Job name/Part name	Quantity		Remarks
	Caliper removal			Remove the parts in order
Drain the brake fluid	Refer to the “BRAKE FLUID
	REPLACEMENT” section in Chapter 3.
Coupling
	Plain washer		Refer to “CALIPER INSTALLATION”
	Brake hose		section
	Caliper support bolt
	Caliper assembly
	Reverse the removal procedure for
installation
