When pushing the caliper piston into the brake caliper, brake fluid level in reservoir tank is incre- asing higher

REPLACING THE BRAKE PADS

REAR BRAKE CHAS

J-10

REAR BRAKE CHAS

REAR BRAKE

BRAKE PAD

28 Nm (2,8 m•kg)

1

6 Nm (0,6 m•kg)

2

NOTE:

It is not necessary disassemble the brake caliper and brake hose to replace the brake pads.

1. Remove:

• Caliper assembly Ø

2. Remove:

• Clip Ø

• Bolt support Ø

• Pad support Ø

• Brake pads

NOTE:

3 2 • Replace the brake pads as a set if either is found to

be worn to the wear limit.

3. Push the caliper piston into the brake caliper by fin- ger.

CAUTION

4. Install:

• Brake pad Ø

2 • Pad support Ø

•

Order	Job name/Part name	Quantity	Remarks
	Brake pad removalCaliper support bolt Caliper assembly Brake pad Pad support			Remove the parts in order
		Refer to “FRONT FORK REMOVAL/ INSTALLATION” section.
	Reverse the removal procedure for installation.

Bolt support Ø

• Clip

4 5. Install:

1 • Caliper assembly

Caliper support bolt 28 Nm (2,8 m•kg)

6. Check:

• Brake fluid level

Refer to “CHECKING THE REAR BRAKE FLUID

LEVEL” section.

7. Check:

• Brake lever operation

Soft spongy feeling —(Bleed the brake system. Refer to “BLEEDING THE HYDRAULIC BRAKE

SYSTEM” section.
